1. DAC performance indicators:
● DAC model:AD9163.
● Resolution: 16 bits.
● DAC update rate: 12GSPS.
● 6GSPS direct RF frequency synthesis.
● DC to 3GHz ( Non- Return-to-Zero NRZ mode).
● DC to 6GHz (2x NRZ mode).
● 1.5GHz to 7.5GHz (mixed mode).
● Optional interpolation 6X, 8X, 12X, 16X, 24X.
● Data transmission: 8 LANE JESD204B.
2. Clock performance indicators:
● DLCK clock is generated by ADF4355.
● Clock chip model: AD9508
● Support onboard clock /external clock, jumper selectable
3. Others:
● Connector: MCX.
● Standard FMC daughter card, compliant with VITA57.1 specification.
● Typical power consumption: 5W.
● Board size: 84.1mm X 69mm.
● Working temperature: -40℃～+85℃.
